LH-LR510 DC precision motor

SPEED：3200rpm

CURRENT：0.030A

TORQUE：21.0g.cm

OUTPUT：0.59W

Consultation

Product Details

型号 MODEL	电压 VOLTAGE		无负荷 NOLOAD		最大效率点 AT MAXIMUM EFFICIENCY					扭力STALL
	使用范围 OPERATING RANGE	额定值NOMINAL	转速SPEED	电流 CURRENT	转速SPEED	电流CURRENT	转矩TORQUE	功率OUTPUT	效率 EFF	扭力STALL
	使用范围 OPERATING RANGE	额定值NOMINAL	rpm	A	rpm	A	g.cm	W	%	g.cm
LRF510NM-16350-31V	1.8-10V	6VCONSTANT	3200	0.030	2720	0.160	21.0	0.59	62.2	140.0
LRF510NM-17290-31V	1.8-10V	6VCONSTANT	4300	0.040	3605	0.210	21.0	0.78	61.3	145.0
LRF510NM-15380-31V	1.8-14V	12VCONSTANT	6300	0.040	5338	0.220	29.0	1.59	60.9	190.0
